Originating from Guangdong, China, our surface-mounted LED aluminum profile is extruded from 6063-T5 high-grade aluminum alloy and treated with a durable anodized finish in sleek silver. Engineered for LED wall washers, cabinet lighting, and architectural strips, this profile offers a lightweight yet robust solution to house LED strips, enhance heat management, and provide a refined aesthetic.
Structure & Materials
• Material: 6063-T5 aluminum alloy ensures structural rigidity and bending strength.
• Surface Finish: Anodized layer imparts corrosion resistance, scratch protection, and UV stability.
• Profile Types: U, V, T, and custom cross-sections with integrated or recessed channels.
• Diffuser Options: PC or PMMA diffusers in frosted, clear, or semi-transparent finishes for uniform light distribution.
• Sealing: Optional silicone gaskets enable IP54-rated installations for damp environments.
Key Features
• Lightweight Construction: Wall thickness of 1.0–2.5 mm, typical weight under 1.2 kg/m.
• High Durability: Withstands temperature range –10 to 60 °C without deformation.
• Efficient Heat Dissipation: High thermal conductivity (≥210 W/m·K) prolongs LED lifespan.
• Corrosion Resistance: Anodized hardness HV200–300, salt spray resistance ≥480 h.
• Easy Installation: Surface-mounted clips, magnetic channels, or screw mounts—no recessed cuts needed.
• Full Customization: Section design, length, color, logo engraving, and accessory integration.
Technical Specifications
– Series: ALP-SM
– Alloy Grade: 6063-T5 Aluminum
– Colors: Standard Silver; optional Black, Champagne Gold, Anthracite
– Dimensions: Width 10–50 mm; Depth 8–30 mm; Length up to 6 m
– Wall Thickness: 1.0 / 1.2 / 1.5 / 2.0 / 2.5 mm
– Protection Rating: IP20 (without gasket); IP54 (with gasket)
– Operating Temp: –40 to +80 °C
– Installation: Surface clips, magnetic strips, screw/flange or suspension kit.
Typical Applications
• Retail & Exhibition: Display lighting, showcases, shelving accent strips.
• Residential: Under-cabinet, wardrobe lighting, staircase handrail illumination.
• Education & Offices: Blackboard lights, desk task lighting, library reading fixtures.
• Hospitality: Corridor guide lighting, bed head reading lights, bar counters.
• Public Spaces: Subway stations, hospital corridors, indoor parking wayfinding.
• Outdoor Accents (IP54): Facade lines, landscape uplights, decorative architectural strips.
Installation & Accessories
• Mounting Clips: Plastic spring clips, aluminum channels, magnetic mounts, suspension cables.
• Diffusers: Frosted, clear, or semi-opaque PC/PMMA covers for glare-free lighting.
• End Caps & Gaskets: Aluminum or plastic end plates with silicone seals for dust/water protection.
• Reflective Inserts: Optional high-reflectivity films or light-guiding plates to enhance output.
• Electrical Components: Quick connectors, terminal blocks, power entry modules, and drivers.
Customization Services
• Profile Design: Tailor cross-section profiles to meet thermal, optical, and structural needs.
• Precise Cutting: Millimeter-accurate length cutting to minimize field adjustments.
• Surface Finishing: Anodized silver standard; optional powder coat, fluorocarbon, or electrostatic paint.
• Branding: Laser or silk-screen logo marking and color-matched batches.
• Integrated Solutions: LED strip integration, constant-current drivers, junction boxes for turnkey supply.
Packaging & Logistics
• Protective Wrapping: Each profile wrapped in plastic film; corners reinforced with EVA or foam.
• Carton Arrangement: Profiles nested with corrugated separators in custom-sized boxes.
• Shipping Terms: EXW, FOB (Shenzhen/Guangzhou), CIF, or DDP per customer preference.
• Transport Options: Support for sea freight, air cargo, and express couriers with tracking and insurance.
Support & Service
• Technical Consultation: Free lighting design guidance and optical simulations by our engineers.
• Installation Training: Video tutorials, user manuals, and on-site support available.
• Warranty: Three-year structural warranty on profiles; one-year accessory warranty.
• After-Sales Care: 7×24 h customer service, rapid replacement of defect parts, periodic satisfaction follow-up.
Conclusion
Our surface-mounted strip light LED aluminum profile combines lightweight extrusion, anodized durability, and efficient thermal performance. Fully customizable and easy to install, it is the ideal linear lighting solution for educational, commercial, residential, and public applications—bringing both form and function to your next lighting project.
